7 Inch HD Quad-view Vehicle Monitor System

No.QW-X10DR-1
HD Security System with 7-inch HD Quad-view Vehicle Monitor support 4CH x 1080P or 720P cameras,etc.
Camera Resolution:
720P
1080P
  • 7 Inch HD Quad-view Vehicle Monitor System,7 Inch HD Quad-view Vehicle Monitor System
  • 7 Inch HD Quad-view Vehicle Monitor System,7 Inch HD Quad-view Vehicle Monitor System
  • 7 Inch HD Quad-view Vehicle Monitor System,7 Inch HD Quad-view Vehicle Monitor System
  • 7 Inch HD Quad-view Vehicle Monitor System,7 Inch HD Quad-view Vehicle Monitor System
  • 7 Inch HD Quad-view Vehicle Monitor System,7 Inch HD Quad-view Vehicle Monitor System

Description

  • Support 4CH x 1080P or 720P cameras
  • Multiple video formats available to cameras: 720P、1080P、NTSC/PAL
  • Multi-display mode
  • Trigger priority can be adjusted freely
  • Resolution: 1024*600
  • Brightness: 500cd/m2
  • DC: 10-32V
  • Easy to install and operate, with innovative functions
  • Suitable for many scenarios, such as indoor / outdoor security systems, vehicle and ship surveillance

    LCD Dimension

    7"

    Resolution

    1024 x 3(RGB) x 600

    Video Input

    4 CH

    Audio Input

    4 CH

    Brightness

    500 cd/m²

    Contrast

    600:1

    Operating Temp. & Humidity

    -20ºC~+70ºC, RH 90%MAX

    Viewing Angle

    U: 85/ D: 85, R/L: 85/85

    Mirror Function

    Yes

    Split Screen

    Yes

    Power Supply

    10V-32V

    Power Consumption

    less than 12W (without cameras)
